30NiCrMo16-6 / 1.6747 Steel
30NiCrMo16-6 Steel for Quenching and Tempering 1.6747 35NCD16
30NiCrMo16-6 / 1.6747 Steel Application
30NiCrMo16-6 / 1.6747 Steel exhibit very good hardenability, impact resistance, load, deformation, wear and tensions resistances.
Used for heavy-duty parts of engines, devices and machines, aviation and aerospace industries, used in the production of crankshafts, gears, shafts, bolts, heat-treated gears and piston rods, etc.
30NiCrMo16-6 / 1.6747 Steel Quality Standard
-DIN EN 10083-3 Steel for quenching and tempering alloy steels.
30NiCrMo16-6 / 1.6747 Steel Chemical Composition per EN 10083-3
GRADE | NUMBER | C | Si | Mn | P | S | Cr | Mo | Ni |
30NiCrMo16-6 | 1.6747 | 0.26-0.33 | ≤ 0.40 | 0.50-0.80 | ≤ 0.025 | ≤ 0.025 | 1.20-1.50 | 0.30-0.60 | 3.30-4.30 |
30NiCrMo16-6 / 1.6747 Steel Mechanical Properties
Heat treatment | Diameter (mm) | Tensile Strength Rm (Mpa) | Yield Strength Rp0.2 (Mpa) | Elongation % in 2″ (%) | Reduction Of Area (%) | Impact Test (J) |
Q+T | 16 max | 1080-1230 | 880 min | 10 min | 45 min | / |
Q+T | 16-40 | 1080-1230 | 880 min | 10 min | 45 min | 35 min |
Q+T | 40-100 | 1080-1230 | 880 min | 10 min | 45 min | 35 min |
Q+T | 100-160 | 900-1050 | 790 min | 11 min | 50 min | 35 min |
Q+T | 160-250 | 900-1050 | 880 min | 11 min | 50 min | 35 min |
30NiCrMo16-6 / 1.6747 Steel Heat treatment
Process | Temperature |
Normalizing annealing | 850 – 880℃ |
Softening annealing | 650 – 700℃ |
Hardening | 865 – 885℃ |
Tempering | 550 – 650℃ |
Hardness in softened state | 269 HB max |
30NiCrMo16-6 / 1.6747 Steel Test
Chemical analysis, Mechnical analysis, Ultrasonic testing, Metallographic, Surface quality and dimension report.
30NiCrMo16-6 / 1.6747 Steel Mill’s Test Certificate
EN 10204/3.1 with all relevant data reg. chem. composition, mech. properties and results of testing.
